Name: XCMG GR2805T PRO 25MPa Road Grading Machine with QSL8.9 Engine
Brand: Shanghai Zekun Machinery Co., Ltd.
SKU: GR2805T Pro
Price: 1.00 USD
Availability: InStock

Home > products > Road Construction Machinery >

XCMG GR2805T PRO 25MPa Road Grading Machine with QSL8.9 Engine

25MPa Road Grading Machine

QSL8.9 Road Grading Machine

XCMG Road Grading Machine

Place of Origin:

Jiangsu, China (Mainland)

Brand Name:

XCMG

Certification:

IOS/CE

Model Number:

GR2805T Pro

Request A Quote

Product Details

Payment & Shipping Terms

Minimum Order Quantity

Price

Call for price

Packaging Details

Container or Shipped by Ro-Ro or Bulk shipment

Delivery Time

7-15days

Payment Terms

T/T

23ton XCMG 3Y263J Static Three Drum Roller China Stage III Equipment

Get Best Price

12ton XCMG 3Y153J Static Drum Roller China Stage III Equipment

Get Best Price

3ton XCMG XMR303 Vibratory Roller China Stage IV Road Machine

Get Best Price

16ton XCMG XS163 Vibratory Roller China Stage II Equipment

Get Best Price

Contact Now

Product Description

Model: Motor Grader	Condition: Brand New	Application: Construction
Brand Name: XCMG	Model Number: GR2805T Pro	Certification: ISO,CE
Rated Working Pressure: 25MPa	Max. Gradeability: ≥30%	Dimension: 10518x2892x3687mm
Total Weight: 23000kg	Engine: QSL8.9	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

XCMG GR2805T PRO 25MPa Road Grading Machine with QSL8.9 Engine 1 　

Item			GR2805T Pro
Basic parameters	Engine model		QSL8.9
	Rated power/speed		242kW/2200rpm
	Machine dimension(standard)		10518x2892x3687mm
	Machine weight(standard)		23000kg
	Tire specification		20.5R25
	Ground clearance (Front axle)		450mm
	Wheel track		2370mm
	Axle distance between front and rear		6774mm
	Wheel base between middle and rear		1771mm
Performance parameters	Drive speed, forward		5.5,8.5,13.2 ,20.3,29.5,43.5km/h
	Drive speed, reverse		5.5,13.2, 29.5km/h
	Traction force f=0.75		2120KN
	Maximum gradeability		≥30%
	Tire inflation pressure		475kPa
	Work system pressure		25MPa
	Transmission box pressure		1.6±0.2Mpa
Working parameters	Maximum steering angle, front wheel		±49°
	Allowable tilt angle, front wheel		±18°
	Maximum oscillation, front axle		±16°
	Maximum oscillation, balance box		Front 15°, rear 15°
	Maximum steering angle, frame		±25°
	Minimum turning radius		8m
	Blade	Maximum it above ground	550mm
		Maximum cutting depth	685mm
		Maximum tit angle	90°
		Cutting angle	Front 40° rear 5°
		Swivel angle	360°
		Length * height	4270x610mm
Capacities	Coolant		50L
	Fuel tank		418L
	Engine		24L
	Transmission box		38L
	Balance box		49L each
	Main reducer and wheel reducer		58.5L
	Hydraulic oil		193L

XCMG GR2805T PRO 25MPa Road Grading Machine with QSL8.9 Engine 2
