Name: XCMG GR2605AU L9 Engine Motor Grader Machine for Construction
Brand: Shanghai Zekun Machinery Co., Ltd.
SKU: GR2605AU
Price: 1.00 USD
Availability: InStock

Home > products > Road Construction Machinery >

XCMG GR2605AU L9 Engine Motor Grader Machine for Construction

XCMG GR2605AU Motor Grader

Construction Motor Grader

L9 Engine Motor Grader

Place of Origin:

Jiangsu, China (Mainland)

Brand Name:

XCMG

Certification:

IOS/CE

Model Number:

GR2605AU

Request A Quote

Product Details

Payment & Shipping Terms

Minimum Order Quantity

Price

Call for price

Packaging Details

Container or Shipped by Ro-Ro or Bulk shipment

Delivery Time

7-15days

Payment Terms

T/T

23ton XCMG 3Y263J Static Three Drum Roller China Stage III Equipment

Get Best Price

12ton XCMG 3Y153J Static Drum Roller China Stage III Equipment

Get Best Price

3ton XCMG XMR303 Vibratory Roller China Stage IV Road Machine

Get Best Price

16ton XCMG XS163 Vibratory Roller China Stage II Equipment

Get Best Price

Contact Now

Product Description

Model: Motor Grader	Condition: Brand New	Application: Construction
Brand Name: XCMG	Model Number: GR2605AU	Certification: ISO, CE
Rated Working Pressure: 24.5MPa	Max. Gradeability: ≥25%	Dimension: 9680×2750×3470mm
Total Weight: 20000kg	Engine: L9	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

Item	Content		Value
Basic parameter	Engine model		L9
	Rated power/speed		206kW/2100rpm
	Machine dimension(standard)		9680×2750×3470mm
	Machine weight(standard)		20000kg
	Tire specification		17.5R25
	Ground clearance (Front axle)		592mm
	Wheel base		2287mm
	Axle distance between front and rear		6636mm
	Wheel base between middle and rear		1696mm
Performance parameters	Drive speed, forward		5,8,13,20,31,44km/h
	Drive speed, reverse		5,14,31km/h
	Traction force f=0.75		≥130kN
	Maximum gradeability		≥25%
	Inflation pressure of tire		425kPa
	Work system pressure		24.5MPa
	Transmission pressure		2.0-2.4Mpa
Working parameters	Maximum steering angle of front wheel		±49°
	Allowable angle of inclination of front wheel		±18°
	Maximum swinging angle of front axle		±16°
	Maximum swinging angle of balance box		Front 15°, rear 15°
	Maximum swinging angle of frame		±25°
	Minimum turning radius		7.8m
	Blade	Maximum lifting height	452mm
		Maximum scraping depth	755mm
		Maximum blade position angle	90°
		Cutting angle	Front 40°,rear 5°
		Angle of revolution	360°
		Length °¡ Height	4270×610mm

XCMG GR2605AU L9 Engine Motor Grader Machine for Construction 2

• Guarantee of delivery
Support online transactions through Alibaba, Verified supplier
-------------------------------------------------------------------------------------------------------------------------------------------
•Which payment terms can you accept?
Normally we can work on the T/T term or L/C term.
1. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled prior to shipment, or against the copy
of original B/L for long-term cooperating clients.
2. On L/C term, a 100% irrevocable L/C without “soft clauses” from an internationally recognized bank can be accepted. Please seek the advice from the individual manager whom you work with.
-------------------------------------------------------------------------------------------------------------------------------------------
•Which INCOTERMS 2010 terms can you work?
We are a professional and sophisticated international player, can handle all INCOTERMS 2010 terms, and we normally work on regular terms such as EXW,FOB,CFR,CIF.
-------------------------------------------------------------------------------------------------------------------------------------------
•How long will your price be valid?
We are a tender and friendly supplier, never greedy on windfall profit. Our price remains stable throughout the year, We only adjust our price based on two situations.
1. The rate of USD, and RMB varies significantly according to the international currency exchange rates;
2. Manufacturers/Factories adjusted the machine price, because of the increasing labor cost and raw material cost.
-------------------------------------------------------------------------------------------------------------------------------------
•WHAT LOGISTICS WAYS CAN YOU WORK FOR SHIPMENT?
We can ship construction machinery with various transportation tools.
1. For 80% of our shipment, the machine will go by sea, to all main continents such as Africa, South America, Middle East. Oceania and Southeast Asia etc., either by container or RoRo / Bulk shipment.
2. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Kyrgyzstan, Tajikistan, Uzbekistan, Turkmenistan, etc., we can send machines by road or railway.
