Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
XCMG
Certification:
IOS/CE
Model Number:
RP905S
| Model: Asphalt Concrete Paver | Condition: Brand New | Application: Construction |
| Brand Name: XCMG | Model Number: RP905S | Certification: ISO,CE |
| Basic paving width: 2500～5000mm | Max. Gradeability: 20% | Main Dimension: 6982X2550X3080mm |
| Total Weight: 22.5ton | Engine: QSB6.7 | Place of Origin: Jiangsu, China (Mainland) |
| Emission Tier: EU Stage III | Color: Yellow | After-sales Service Provided: Engineers available to service machinery overseas |
| Item | Unit | RP905S E500BTV/RP905S E600BTV |
| Basic paving width | m | 2.5～5/3.0～6 |
| Maximum paving width | m | 8.0/9.0 |
| Maximum paving thickness | mm | 500 |
| Maximum operating speed | m/min | 25 |
| Maximum traveling speed | km/h | 4 |
| Theoretical productivity | t/h | 900 |
| Hopper capacity | t | 15 |
| Gradeability | ％ | 20 |
| Flatness (standard deviation) | mm | 1.2 |
| Cross slope error | % | ±0.2 |
| Arch adjustment range | % | -1.5～+4.5 |
| Diesel engine model | / | QSB6.7 |
| Rated power of diesel engine | kW | 158 |
| Rated speed of diesel engine | r/min | 2000 |
| Distributing speed | r/min | 0～110 |
| Conveying speed | m/min | 0～34 |
| Vibrating speed | r/min | 0～1500 |
| Vibrating amplitude | mm | 4 |
| Vibration frequency | Hz | 0～50 |
| Overall weight | t | 22.5～23.8/23.5~24.5 |
| Transportation outline dimensions | mm | 6982X2550X3080/6982X3000X3080 |
| Diesel tank capacity | L | 240 |
| Hydraulic oil tank capacity | L | 260 |
| Heating mode of screed | / | Electric heating |
| Heating generator power | kW | 40( Variable frequency ) |
| Control mode of conveying level | / | Angle sensing integrated automatic control |
| Control mode of distributing level | / | Ultrasonic sensing automatic control |
| Control mode of automatic leveling | / | Two-longitudinal & one-transverse levelling device |
