Name: 7.6ton 1.1m 2.0m XCMG RP305 PAVER EC Stage V road construction equipment
Brand: Shanghai Zekun Machinery Co., Ltd.
SKU: RP305
Price: 1.00 USD
Availability: InStock

Home > products > Road Construction Machinery >

7.6ton 1.1m 2.0m XCMG RP305 PAVER EC Stage V road construction equipment

Asphalt Road Construction Equipment

Construction Road Equipment

Equipment Used In Construction Of Road

Place of Origin:

Jiangsu, China (Mainland)

Brand Name:

XCMG

Certification:

IOS/CE

Model Number:

RP305

Request A Quote

Product Details

Payment & Shipping Terms

Minimum Order Quantity

Price

Call for price

Packaging Details

Container or Shipped by Ro-Ro or Bulk shipment

Delivery Time

7-15days

Payment Terms

T/T

23ton XCMG 3Y263J Static Three Drum Roller China Stage III Equipment

Get Best Price

12ton XCMG 3Y153J Static Drum Roller China Stage III Equipment

Get Best Price

3ton XCMG XMR303 Vibratory Roller China Stage IV Road Machine

Get Best Price

16ton XCMG XS163 Vibratory Roller China Stage II Equipment

Get Best Price

Contact Now

Product Description

Model: Asphalt Concrete Paver	Condition: Brand New	Application: Construction
Brand Name: XCMG	Model Number: RP305	Certification: ISO, CE
Basic paving width: 1100-2000mm	Max. Gradeability: 20%	Main Dimension: 4910X1450X1980mm
Total Weight: 7.6ton	Engine: Kubota	Place of Origin: Jiangsu, China (Mainland)
Emission Tier: EC Stage V	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

Item	Content	Unit	RP305
Basic parameters	Basic paving width	mm	1100~2000
	Max. paving width	mm	3200
	Max. pave thickness	mm	200
	Max. paving speed	m/min	30
	Max. drive speed	km/h	3.6
	Maximum theoretical productivity	t/h	260
	Max. gradeability	%	20
Engine	Manufacturer	-	Kubota
	Model	-	V3800
	Emission	-	EC Stage V
	Fuel	-	Diesel
	Rated power	kW	55.4
	Rated speed	rpm	2200
Crawler	Grounding length	mm	1703
Crawler	Track width	mm	180
Conveyor	Hopper capacity	t	5.8
	Scraper numbers	-	1
	Scraper speed(maximum)	m/min	25
Auger	Speed(maximum)	rpm	70
Auger	Diameter	mm	300
Electrical system	Battery voltage	V	24
Weight	Tractor weight	t	6.2
	Operating weight	t	7.6
	Total weight	t	7.8
Noise	Sound pressure level LPA at the operator ears	dB(A)	90
Noise	Emitted sound level	dB(A)	104
Main configuration	1. Kubota EC Stage Ⅴ engine with 55.4kW;
	2. E1120TV hydraulic extending screed(single tamper+vibrator+electric heating);
	3. Standard intelligent control system;
	4. MOBA leveling instrument/material level instrument;
	5. Wireless remote control.
Options	1. Bolt-on extensions: 2x0.45m+2x0.15m, maximum paving width 3.2m.
	2. Bolt-on extensions: 2x0.45m, maximum paving width 2.9m.
	3. Bolt-on extensions: 2x0.15m, maximum paving width 2.3m.
	4. Cut-off shoes.

7.6ton 1.1m 2.0m XCMG RP305 PAVER EC Stage V road construction equipment 2

• Guarantee of delivery
Support online transactions through Alibaba, Verified supplier
-------------------------------------------------------------------------------------------------------------------------------------------
•Which payment terms can you accept?
Normally we can work on the T/T term or L/C term.
1. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled prior to shipment, or against the copy
of original B/L for long-term cooperating clients.
2. On L/C term, a 100% irrevocable L/C without “soft clauses” from an internationally recognized bank can be accepted. Please seek the advice from the individual manager whom you work with.
-------------------------------------------------------------------------------------------------------------------------------------------
•Which INCOTERMS 2010 terms can you work?
We are a professional and sophisticated international player, can handle all INCOTERMS 2010 terms, and we normally work on regular terms such as EXW,FOB,CFR,CIF.
-------------------------------------------------------------------------------------------------------------------------------------------
•How long will your price be valid?
We are a tender and friendly supplier, never greedy on windfall profit. Our price remains stable throughout the year, We only adjust our price based on two situations.
1. The rate of USD, and RMB varies significantly according to the international currency exchange rates;
2. Manufacturers/Factories adjusted the machine price, because of the increasing labor cost and raw material cost.
-------------------------------------------------------------------------------------------------------------------------------------
•WHAT LOGISTICS WAYS CAN YOU WORK FOR SHIPMENT?
We can ship construction machinery with various transportation tools.
1. For 80% of our shipment, the machine will go by sea, to all main continents such as Africa, South America, Middle East. Oceania and Southeast Asia etc., either by container or RoRo / Bulk shipment.
2. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Kyrgyzstan, Tajikistan, Uzbekistan, Turkmenistan, etc., we can send machines by road or railway.
