Name: 19.2Ton 2.5m Up XCMG RP603 Paver EC Stage III Road Construction
Brand: Shanghai Zekun Machinery Co., Ltd.
SKU: RP603
Price: 1.00 USD
Availability: InStock

Home > Products > Road Construction Machinery >

19.2Ton 2.5m Up XCMG RP603 Paver EC Stage III Road Construction

Asphalt Road Construction Equipment

Construction Road Equipment

Equipment Used In Construction Of Road

Place of Origin:

Jiangsu, China (Mainland)

Brand Name:

XCMG

Certification:

IOS/CE

Model Number:

RP603

Request A Quote

Product Details

Highlight:

Asphalt Road Construction Equipment

Construction Road Equipment

Equipment Used In Construction Of Road

Payment & Shipping Terms

Minimum Order Quantity

Price

Call for price

Packaging Details

Container or Shipped by Ro-Ro or Bulk shipment

Delivery Time

7-15days

Payment Terms

T/T

ROAD CONSTRUCTION XCMG GR5505T PRO LAGER MINING MOTOR GRADER 30% GRADEABILITY 25MPA

Get Best Price

2019 Cat 140GC with only 10,316 working hours for sale

Get Best Price

2018 SEM919 Motor Grader for Sale

Get Best Price

26ton XCMG XP263 Tire Roller China Stage III Road Construction Equipment

Get Best Price

Contact Now

Product Description

Model: Asphalt Concrete Paver	Condition: Brand New	Application: Construction
Brand Name: XCMG	Model Number: RP603	Certification: ISO, CE
Basic paving width: 2500-4750mm	Max. Gradeability: 20%	Main Dimension: 6680X3387X4000mm
Total Weight: 19.2ton	Engine: QSB6.7	Place of Origin: Jiangsu, China (Mainland)
Emission Tier: EC Stage III	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

Item	Content	Unit	RP603
Basic parameters	Basic paving width	mm	2500～4750
	Max. paving width (Options)	mm	6000
	Max. pave thickness	mm	400
	Max. paving speed	m/min	20
	Max. drive speed	km/h	3
	Maximum theoretical productivity	t/h	600
	Max. gradeability	%	20
Engine	Manufacturer	-	Cummins
	Model	-	QSB6.7
	Emission	-	EC Stage Ⅲ
	Fuel	-	Diesel
	Rated power	kW	129
	Rated speed	rpm	2200
Crawler	Grounding length	mm	3175
Crawler	Track width	mm	300
Conveyor	Hopper capacity	t	14
	Scraper numbers	-	2
	Scraper speed(maximum)	m/min	25
Auger	Speed(maximum)	rpm	80
Auger	Diameter	mm	420
Electrical system	Battery voltage	V	24
Weight	Tractor weight	t	16
	Operating weight	t	18.5
	Total weight	t	19.2
Noise	Sound pressure level LPA at the operator ears	dB(A)	86
Noise	Emitted sound level	dB(A)	105
Main configuration	1. Cummins EC Stage Ⅲ engine with 129kW.
	2. E475TV hydraulic extending screed(electric heating, single tamper).
	3. Standard intelligent control system.
	4. MOBA leveling instrument/material level instrument.
Options	1. E475T bolt-on extension: 2x0.625m, maximum paving width 6m.
Options	2. Diesel spraying device.

19.2Ton 2.5m Up XCMG RP603 Paver EC Stage III Road Construction 2

• Guarantee of delivery
Support online transactions through Alibaba, Verified supplier
-------------------------------------------------------------------------------------------------------------------------------------------
•Which payment terms can you accept?
Normally we can work on the T/T term or L/C term.
1. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled prior to shipment, or against the copy
of original B/L for long-term cooperating clients.
2. On L/C term, a 100% irrevocable L/C without “soft clauses” from an internationally recognized bank can be accepted. Please seek the advice from the individual manager whom you work with.
-------------------------------------------------------------------------------------------------------------------------------------------
•Which INCOTERMS 2010 terms can you work?
We are a professional and sophisticated international player, can handle all INCOTERMS 2010 terms, and we normally work on regular terms such as EXW,FOB,CFR,CIF.
-------------------------------------------------------------------------------------------------------------------------------------------
•How long will your price be valid?
We are a tender and friendly supplier, never greedy on windfall profit. Our price remains stable throughout the year, We only adjust our price based on two situations.
1. The rate of USD, and RMB varies significantly according to the international currency exchange rates;
2. Manufacturers/Factories adjusted the machine price, because of the increasing labor cost and raw material cost.
-------------------------------------------------------------------------------------------------------------------------------------
•WHAT LOGISTICS WAYS CAN YOU WORK FOR SHIPMENT?
We can ship construction machinery with various transportation tools.
1. For 80% of our shipment, the machine will go by sea, to all main continents such as Africa, South America, Middle East. Oceania and Southeast Asia etc., either by container or RoRo / Bulk shipment.
2. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Kyrgyzstan, Tajikistan, Uzbekistan, Turkmenistan, etc., we can send machines by road or railway.
