Name: 19.2Ton 2.5m Up XCMG RP603 Paver EC Stage III Road Construction
Brand: Shanghai Zekun Machinery Co., Ltd.
SKU: RP603
Price: 1.00 USD
Availability: InStock

Home > products > Road Construction Machinery >

19.2Ton 2.5m Up XCMG RP603 Paver EC Stage III Road Construction

Asphalt Road Construction Equipment

Construction Road Equipment

Equipment Used In Construction Of Road

Place of Origin:

Jiangsu, China (Mainland)

Brand Name:

XCMG

Certification:

IOS/CE

Model Number:

RP603

Request A Quote

Product Details

Payment & Shipping Terms

Minimum Order Quantity

Price

Call for price

Packaging Details

Container or Shipped by Ro-Ro or Bulk shipment

Delivery Time

7-15days

Payment Terms

T/T

23ton XCMG 3Y263J Static Three Drum Roller China Stage III Equipment

Get Best Price

12ton XCMG 3Y153J Static Drum Roller China Stage III Equipment

Get Best Price

3ton XCMG XMR303 Vibratory Roller China Stage IV Road Machine

Get Best Price

16ton XCMG XS163 Vibratory Roller China Stage II Equipment

Get Best Price

Contact Now

Product Description

Model: Asphalt Concrete Paver	Condition: Brand New	Application: Construction
Brand Name: XCMG	Model Number: RP603	Certification: ISO, CE
Basic paving width: 2500-4750mm	Max. Gradeability: 20%	Main Dimension: 6680X3387X4000mm
Total Weight: 19.2ton	Engine: QSB6.7	Place of Origin: Jiangsu, China (Mainland)
Emission Tier: EC Stage III	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

Item	Content	Unit	RP603
Basic parameters	Basic paving width	mm	2500～4750
	Max. paving width (Options)	mm	6000
	Max. pave thickness	mm	400
	Max. paving speed	m/min	20
	Max. drive speed	km/h	3
	Maximum theoretical productivity	t/h	600
	Max. gradeability	%	20
Engine	Manufacturer	-	Cummins
	Model	-	QSB6.7
	Emission	-	EC Stage Ⅲ
	Fuel	-	Diesel
	Rated power	kW	129
	Rated speed	rpm	2200
Crawler	Grounding length	mm	3175
Crawler	Track width	mm	300
Conveyor	Hopper capacity	t	14
	Scraper numbers	-	2
	Scraper speed(maximum)	m/min	25
Auger	Speed(maximum)	rpm	80
Auger	Diameter	mm	420
Electrical system	Battery voltage	V	24
Weight	Tractor weight	t	16
	Operating weight	t	18.5
	Total weight	t	19.2
Noise	Sound pressure level LPA at the operator ears	dB(A)	86
Noise	Emitted sound level	dB(A)	105
Main configuration	1. Cummins EC Stage Ⅲ engine with 129kW.
	2. E475TV hydraulic extending screed(electric heating, single tamper).
	3. Standard intelligent control system.
	4. MOBA leveling instrument/material level instrument.
Options	1. E475T bolt-on extension: 2x0.625m, maximum paving width 6m.
Options	2. Diesel spraying device.
