Name: 22.8ton 2.5m 5m XCMG RP803 PAVER EC Stage III road construction equipment
Brand: Shanghai Zekun Machinery Co., Ltd.
SKU: RP803
Price: 1.00 USD
Availability: InStock

Home > products > Road Construction Machinery >

22.8ton 2.5m 5m XCMG RP803 PAVER EC Stage III road construction equipment

Asphalt Road Construction Equipment

Construction Road Equipment

Equipment Used In Construction Of Road

Place of Origin:

Jiangsu, China (Mainland)

Brand Name:

XCMG

Certification:

IOS/CE

Model Number:

RP803

Request A Quote

Product Details

Payment & Shipping Terms

Minimum Order Quantity

Price

Call for price

Packaging Details

Container or Shipped by Ro-Ro or Bulk shipment

Delivery Time

7-15days

Payment Terms

T/T

23ton XCMG 3Y263J Static Three Drum Roller China Stage III Equipment

Get Best Price

12ton XCMG 3Y153J Static Drum Roller China Stage III Equipment

Get Best Price

3ton XCMG XMR303 Vibratory Roller China Stage IV Road Machine

Get Best Price

16ton XCMG XS163 Vibratory Roller China Stage II Equipment

Get Best Price

Contact Now

Product Description

Model: Asphalt Concrete Paver	Condition: Brand New	Application: Construction
Brand Name: XCMG	Model Number: RP803	Certification: ISO, CE
Basic paving width: 2500-5000mm	Max. Gradeability: 20%	Main Dimension: 7080X3387X4000mm
Total Weight: 22.8ton	Engine: QSB6.7	Place of Origin: Jiangsu, China (Mainland)
Emission Tier: EC Stage III	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

Item	Content	Unit	RP803
Basic parameters	Basic paving width	mm	2500～5000
	Max. paving width (Options)	mm	6500～8000
	Max. pave thickness	mm	400
	Max. paving speed	m/min	20
	Max. drive speed	km/h	3
	Maximum theoretical productivity	t/h	800
	Max. gradeability	%	20
Engine	Manufacturer	-	Cummins
	Model	-	QSB6.7
	Emission	-	EC Stage Ⅲ
	Fuel	-	Diesel
	Rated power	kW	142
	Rated speed	rpm	2000
Crawler	Grounding length	mm	3175
Crawler	Track width	mm	300
Conveyor	Hopper capacity	t	14
	Scraper numbers	-	2
	Scraper speed(maximum)	m/min	27
Auger	Speed(maximum)	rpm	90
Auger	Diameter	mm	420
Electrical system	Battery voltage	V	24
Weight	Tractor weight	t	16.7
	Operating weight	t	20.5
	Total weight	t	22.8
Noise	Sound pressure level LPA at the operator ears	dB(A)	86
Noise	Emitted sound level	dB(A)	105
Main configuration	1. Cummins EC Stage III engine with 142kW;
	2. E500A four support hydraulic extending screed(electric heating, single tamper);
	3. Standard intelligent control system;
	4. MOBA leveling instrument/material level instrument;
	5. Automatic centralized lubrication;
Options	1. E500A bolt-on extension: 4x0.75m, maximum paving width 8m.
	2. E500A bolt-on extension: 2x0.75m, maximum paving width 6.5m.
	3. Diesel spraying device.
	4. Eccentric vibration;
	5. Change to E600T hydraulic extending screed, basic width 3-5.85m;
	6. E600T extension: 2x0.9m+2x0.25m, maximum paving width 8.15m.
