Name: 13.5 Ton XCMG XM1005H Cold Milling Machines Use In Road Construction
Brand: Shanghai Zekun Machinery Co., Ltd.
SKU: XM1005H
Price: 1.00 USD
Availability: InStock

Home > Products > Road Construction Machinery >

13.5 Ton XCMG XM1005H Cold Milling Machines Use In Road Construction

13.5 Ton Cold Milling Machines

Road Construction Cold Milling Machines

XM1005H Cold Milling Machines

Place of Origin:

Jiangsu, China (Mainland)

Brand Name:

XCMG

Certification:

IOS/CE

Model Number:

XM1005H

Request A Quote

Product Details

Highlight:

13.5 Ton Cold Milling Machines

Road Construction Cold Milling Machines

XM1005H Cold Milling Machines

Payment & Shipping Terms

Minimum Order Quantity

Price

Call for price

Packaging Details

Container or Shipped by Ro-Ro or Bulk shipment

Delivery Time

7-15days

Payment Terms

T/T

ROAD CONSTRUCTION XCMG GR5505T PRO LAGER MINING MOTOR GRADER 30% GRADEABILITY 25MPA

Get Best Price

2019 Cat 140GC with only 10,316 working hours for sale

Get Best Price

2018 SEM919 Motor Grader for Sale

Get Best Price

26ton XCMG XP263 Tire Roller China Stage III Road Construction Equipment

Get Best Price

Contact Now

Product Description

Model: Cold Milling Machine	Condition: Brand New	Application: Construction
Brand Name: XCMG	Model Number: XM1005H	Certification: ISO, CE
Max.Milling Width:1000mm	Max.Milling Depth:220mm	Overall Dimension: 12290×1400×4900mm
Number of Cutters: 80	Drum Diameter of Cutter:860mm	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Operating Weight: 13500kg	After-sales Service Provided: Engineers available to service machinery overseas

Item	Content	Unit	XM1005H
Milling drum	Milling width	mm	1000
	Milling depth	mm	220
	Space between tools	mm	18
	Quantity of tools		80
	Rotor diameter including tool	mm	860
Engine	Manufacturer		Dongfeng Cummins
	Model		QSB6.7
	Cooling mode		Water-cooling
	Number of cylinders		6
	Rated power	kW	164
	Displacement	L	6.7
	Full-load fuel consumption	L	47
	Comprehensive fuel consumption	L	15
	Emission standard		EU Stage 3a/CN Stage 3
Electric system	Voltage	V	24
Tank volume	Fuel tank	L	500
	Water tank	L	850
	Hydraulic oil tank	L	120
Traveling performance	Working speed	m/min	0-50
	Traveling speed	km/h	0-8.5
	Theoretic gradability	%	57
	Minimum ground clearance	mm	205
Tire	Specification	mm x mm	660×250
Conveying belt	Belt width	mm	400
Conveying belt	Theoretic conveying capacity	m3/h	92
Overall eight	Weight in transportation state	kg	12800
Overall eight	working mass	kg	13500

13.5 Ton XCMG XM1005H Cold Milling Machines Use In Road Construction 2

• Guarantee of delivery
Support online transactions through Alibaba, Verified supplier
-------------------------------------------------------------------------------------------------------------------------------------------
•Which payment terms can you accept?
Normally we can work on the T/T term or L/C term.
1. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled prior to shipment, or against the copy
of original B/L for long-term cooperating clients.
2. On L/C term, a 100% irrevocable L/C without “soft clauses” from an internationally recognized bank can be accepted. Please seek the advice from the individual manager whom you work with.
-------------------------------------------------------------------------------------------------------------------------------------------
•Which INCOTERMS 2010 terms can you work?
We are a professional and sophisticated international player, can handle all INCOTERMS 2010 terms, and we normally work on regular terms such as EXW,FOB,CFR,CIF.
-------------------------------------------------------------------------------------------------------------------------------------------
•How long will your price be valid?
We are a tender and friendly supplier, never greedy on windfall profit. Our price remains stable throughout the year, We only adjust our price based on two situations.
1. The rate of USD, and RMB varies significantly according to the international currency exchange rates;
2. Manufacturers/Factories adjusted the machine price, because of the increasing labor cost and raw material cost.
-------------------------------------------------------------------------------------------------------------------------------------
•WHAT LOGISTICS WAYS CAN YOU WORK FOR SHIPMENT?
We can ship construction machinery with various transportation tools.
1. For 80% of our shipment, the machine will go by sea, to all main continents such as Africa, South America, Middle East. Oceania and Southeast Asia etc., either by container or RoRo / Bulk shipment.
2. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Kyrgyzstan, Tajikistan, Uzbekistan, Turkmenistan, etc., we can send machines by road or railway.
