Name: 21.5 Ton XCMG XM1205F Milling Machine Road Construction Equipment
Brand: Shanghai Zekun Machinery Co., Ltd.
SKU: XM1205F
Price: 1.00 USD
Availability: InStock

Home > Products > Road Construction Machinery >

21.5 Ton XCMG XM1205F Milling Machine Road Construction Equipment

Road Construction Equipment Milling Machine

21.5 Ton Milling Machine

XM1205F Milling Machine

Place of Origin:

Jiangsu, China (Mainland)

Brand Name:

XCMG

Certification:

IOS/CE

Model Number:

XM1205F

Request A Quote

Product Details

Highlight:

Road Construction Equipment Milling Machine

21.5 Ton Milling Machine

XM1205F Milling Machine

Payment & Shipping Terms

Minimum Order Quantity

Price

Call for price

Packaging Details

Container or Shipped by Ro-Ro or Bulk shipment

Delivery Time

7-15days

Payment Terms

T/T

ROAD CONSTRUCTION XCMG GR5505T PRO LAGER MINING MOTOR GRADER 30% GRADEABILITY 25MPA

Get Best Price

2019 Cat 140GC with only 10,316 working hours for sale

Get Best Price

2018 SEM919 Motor Grader for Sale

Get Best Price

26ton XCMG XP263 Tire Roller China Stage III Road Construction Equipment

Get Best Price

Contact Now

Product Description

Model: Cold Milling Machine	Condition: Brand New	Application: Construction
Brand Name: XCMG	Model Number: XM1205F	Certification: ISO, CE
Max.Milling Width:1200mm	Max.Milling Depth:320mm	Overall Dimension: 12700×2700×3700mm
Number of Cutters: 100	Drum Diameter of Cutter:980mm	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Operating Weight: 21500kg	After-sales Service Provided: Engineers available to service machinery overseas

Item	Content	Unit	XM1205F
Milling drum	Milling width	mm	1200
	Milling depth[1]	mm	320
	Space between tools	mm	18
	Quantity of tools		100
	Rotor diameter including tool	mm	980
Engine	Manufacturer		SDEC
	Model		SC9DK260G3
	Cooling mode		Water-cooling
	Number of cylinders		6
	Rated power	kW/rpm	192/2200
	Displacement	L	8.8
	Full-load fuel consumption	Uh	46.5
	Comprehensive fuel consumption	Uh	19.5
	Emission standard		EU Stage 3a/CN Stage 3
Electric system	Voltage	V	24
Tank volume	Fuel tank	L	480
	Water tank	L	120
	Hydraulic oil tank	L	1600
Travelingp erformance	Working speed	m/min	0-30
	Traveling speed	km/h	0-5
	Theoretic gradeability	%	80
	Ground clearance of milling drum	mm	300
Track	Dimension of front track	mm	1330x260x550
Conveyiny of milling material	Width of conveying belt	mm	600
	Width of aggregate belt	mm	600
	Theoretic conveying capacity	m3/h	176
	Swinging angle of conveying belt		±60
	Conveying height	mm	5000
	Transportation dimension of main unit (LxWxH)	mm	9950x2180x3000
Machine mass	No-load mass	kg	20000
Machine mass	working mass	kg	21500

21.5 Ton XCMG XM1205F Milling Machine Road Construction Equipment 2

• Guarantee of delivery
Support online transactions through Alibaba, Verified supplier
-------------------------------------------------------------------------------------------------------------------------------------------
•Which payment terms can you accept?
Normally we can work on the T/T term or L/C term.
1. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled prior to shipment, or against the copy
of original B/L for long-term cooperating clients.
2. On L/C term, a 100% irrevocable L/C without “soft clauses” from an internationally recognized bank can be accepted. Please seek the advice from the individual manager whom you work with.
-------------------------------------------------------------------------------------------------------------------------------------------
•Which INCOTERMS 2010 terms can you work?
We are a professional and sophisticated international player, can handle all INCOTERMS 2010 terms, and we normally work on regular terms such as EXW,FOB,CFR,CIF.
-------------------------------------------------------------------------------------------------------------------------------------------
•How long will your price be valid?
We are a tender and friendly supplier, never greedy on windfall profit. Our price remains stable throughout the year, We only adjust our price based on two situations.
1. The rate of USD, and RMB varies significantly according to the international currency exchange rates;
2. Manufacturers/Factories adjusted the machine price, because of the increasing labor cost and raw material cost.
-------------------------------------------------------------------------------------------------------------------------------------
•WHAT LOGISTICS WAYS CAN YOU WORK FOR SHIPMENT?
We can ship construction machinery with various transportation tools.
1. For 80% of our shipment, the machine will go by sea, to all main continents such as Africa, South America, Middle East. Oceania and Southeast Asia etc., either by container or RoRo / Bulk shipment.
2. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Kyrgyzstan, Tajikistan, Uzbekistan, Turkmenistan, etc., we can send machines by road or railway.
