Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
XCMG
Certification:
IOS/CE
Model Number:
CV163U
| Model: Road Roller | Condition: Brand New | Application: Construction |
| Brand Name: XCMG | Model Number: CV163U | Certification: ISO, CE |
| Operating Weight: 16000kgs | Drum width: 2130mm | Dimension: 6134×2300×3200mm |
| Working speed(F/R): 0-11km//h | Theoretical gradability: 60% | Place of Origin: Jiangsu, China (Mainland) |
| Warranty: 1 year | Engine Model: B4.5 | After-sales Service Provided: Engineers available to service machinery overseas |
| Item | Content | Unit | CV163U/CV163PDU |
| Weights | Operating weight | kg | 16000/16500 |
| Distributed weight of front drum | kg | 10000/10500 | |
| Distributed weight of rear drum | kg | 6000 | |
| Static linear load | N/cm | 49.3/- | |
| Propelling | Operating speed | km/h | 0-5; 0-11 |
| Theoretical gradeability | % | 63%/60% | |
| Minimum turning radius(intern/extern) | mm | 4670; 6800 | |
| Minimum ground clearance | mm | 431/510 | |
| Wheel base | mm | 3030 | |
| Steering angle | ° | 30 | |
| Oscillation angle | ° | 10 | |
| Braking distance | m | 3.9 | |
| Compaction Performance |
Vibration frequency | Hz | 28; 33 |
| Nominal amplitude | mm | 2.0 ; 1.0/1.8; 0.9 | |
| Exciting force (High/low frequency) | kN | 340; 236 | |
| Drum diameter | mm | 1523/1511 | |
| Drum width | mm | 2130 | |
| Refilling pressure of drive system | MPa | 2.4 | |
| Max. Pressure of drive system | MPa | 38 | |
| Max. Pressure of vibration system | MPa | 32 | |
| Max. Pressure of steering system | MPa | 14 | |
| Engine | Model | - | B4.5 |
| Type | - | Turbocharger water-cooled electrical control | |
| Rated power | kW | 129 | |
| Rated speed | r/min | 2200 | |
| Tire | Specification | - | 23.1-26-12G23TL I 23.1-26-12R1TL |
| Ply rating | - | 12 | |
| Air pressure | kPa | 200/170 | |
| Others | Drive mode | - | Hydrostatic closed type |
| Vibration type | - | Hydrostatic closed type | |
| Service brake | - | Hydraulic | |
| Parking brake | - | Mechanic/hydraulic | |
| Emergency braking | - | Mechanic/hydraulic | |
| Steering mode | - | Articulated | |
| Steering control | - | Hydraulic |
